Standards about the Bundy tubes, and related fields, from GB, GBT, ASTM, SAE, ASTM and automotive manufacturers.
1 Scope This standard applies to brake pipes with and without flares for installation in hydraulic braking systems. 2 Dimensions, designations 2.1 Pipes without flares B Double-walled rolled pipeC Welded and drawn pipeD Seamless drawn pipe Designation of a double-walled rolled steel brake pipe without flare complying with Table 6(B), with an outer pipe diameter […]
1 Scope This international standard specifies the essential dimensions of physical characteristics for metallic pipes, pipes with single flares, tapped holes, male fittings and hose end fittings used in hydraulic braking systems for road vehicles. 2 Normative reference The following standard contains provisions which, through reference in this text, constitute provisions of this International Standard.
Foreword This DBL refers to the characteristics and requirements for tubes for brake and fuel lines as well as aluminum tubes for regeneration and breather lines. Tubing for other applications such as hydraulic lines are not covered by this DBL.This edition supersedes the previous edition of this Standard dated 2013-12. Application note:In line with the
C12200 copper pipes made to ASTM B68 for automotive.
1. Standard & Practices: To comply with all requirements of ASTM A254 2. Hardness: (On ID 90 degree from Seam) Rockwell 30T 55 Maximum. 3. Flatten & Bend Test: A section of the tubing 2-1/2″ minimum long shall stand being flattened between parallel plates until the inside walls are in contact. The flattened section shall
This standard applies to steel convoluted double-layer brazed pipes intended for pipelines of hydraulic systems of combines, tractors, automobiles, household refrigerators, etc. 1. Assortment 1.1. The shape, dimensions and mass of 1 m of pipes must correspond to those indicated in Fig. 1 and in Table 1. Table 1 Sizes & Weights Outside Diameter Weight, kg/meter
0. FOREWORD 0.1 This Indian Standard was adopted by the Indian Standards Institution on 15 July 1976, after the draft finalized by the Steel Tubes, Pipes and Fittings Sectional Committee had been approved by the Structural and Metals Division Council.0.2 There has been a long felt need for copper brazed steel tubes used specially in automotive,
1. SCOPE This SAE Standard is intended to establish uniform methods for testing certain types of carbon steel and alloy steel tubing listed in 2.1.1. The specified test and performance criteria applicable to each variety of tubing are set forth in the respective SAE J Specifications. 2. REFERENCES 2.1 Applicable Publications The following publications form
